Single Stage Single Suction Centrifugal Pump
Created with Pixso.

Compact Vertical Single Stage Single Suction Centrifugal Water Pump for Water Supply & Drainage

Compact Vertical Single Stage Single Suction Centrifugal Water Pump for Water Supply & Drainage

Brand Name: ZY
Model Number: XBD
MOQ: 1pcs
Price: $500-$2000
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500pcs/month
Detail Information
Place of Origin:
China
Structure:
Single-stage Pump
Pressure:
High Pressure
Motor:
Exproof/non-exproof
Usage:
Water
Power:
0.55-160KW
Feature:
Corrosion Resistance And Friction Resistance
Application:
Water Supply, Drainage, Fire Fighting, Etc.
Brand:
OEM
Caliber:
25-200mm
Flow Rate:
0.6-400m3/h
Head:
5-125m
Impeller:
Single Stage Single Suction
Inlet Pressure:
≤1.6MPa
Installation Method:
Horizontal, Vertical
Material:
Cast Iron, Stainless Steel
Outlet Pressure:
≤1.0MPa
Shaft Seal:
Packing Seal, Mechanical Seal
Speed:
1450-2900r/min
Temperature:
≤120℃
Packaging Details:
wooden
Supply Ability:
500pcs/month
Highlight:

Vertical Centrifugal Fire Fighting Water Pump

,

Fire Fighting Water Pump Corrosion Resistance

,

Red vertical fire fighting pump

Product Description

China water pumps vertical single stage single suction centrifugal fire fighting water pump



Introduction

Product Feature:

> Compact structure, small volume, beautiful outlook

>Easy to mount

>Stable working, low noise, high concentricity of components

>No leakage

> Easy to maintaince

Product Application

LISG series vertical centrifugal pump is used to transport clean water and other liquids,whose physical properties are similar to clean water.

> Industrial and urban water supply and drainage

> High-rise building pressurized water

> Garden irrigation

> Long distance water delivery

> Bathroom heating and cooling water circulation pressurization and equipmentSpecification







Specification:

No. Model Flow(m3/h) Head(m) Power(kw) Speed(rpm)
75 50-250(I)B 21.6 60 11 2900
76 50-315(I) 25 125 30 2900
77 50-315(I)A 23.7 113 22 2900
78 50-315(I)B 22.5 101 18.5 2900
79 50-315(I)C 20.6 85 15 2900
80 65-100 25 12.5 1.5 2900
81 65-100A 22.3 10 1.1 2900
82 65-125 25 20 3 2900
83 65-125A 22.3 16 2.2 2900
84 65-160 25 32 4 2900
85 65-160A 23.4 28 4 2900
86 65-160B 21.6 24 3 2900
87 65-200 25 50 7.5 2900
88 65-200A 23.5 44 7.5 2900
89 65-200B 21.8 38 5.5 2900
90 65-250 25 80 15 2900
91 65-250A 23.4 70 11 2900
92 65-250B 21.6 60 11 2900
93 65-315 25 125 30 2900
94 65-315A 23.7 113 22 2900
95 65-315B 22.5 101 18.5 2900
96 65-315C 20.6 85 15 2900
97 65-100(I) 50 12.5 3 2900
98 65-100(I)A 44.7 10 2.2 2900
99 65-125(I) 50 20 5.5 2900
100 65-125(I)A 44.7 16 4 2900
101 65-160(I) 50 32 7.5 2900
102 65-160(I)A 46.7 28 7.5 2900
103 65-160(I)B 43.3 24 5.5 2900
104 65-200(I) 50 50 15 2900
105 65-200(I)A 47 44 11 2900
106 65-200(I)B 43.5 38 7.5 2900
107 65-250(I) 50 80 22 2900
108 65-250(I)A 46.7 70 18.5 2900
109 65-250(I)B 43.3 60 15 2900
110 65-315(I) 50 125 37 2900
111 65-315(I)A 46.5 110 30 2900
