Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer

Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer

Brand Name: ZY
Model Number: QJB-W
MOQ: 1set
Price: $50-$2000
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000set/month
Detail Information
Place of Origin:
Zhejiang, China
Certification:
ISO9001
Structure:
Pump
Application:
Acid Liquid
Rated Current:
4 A
Propeller Rpm:
960 R/min
Diameter Of Blade:
260 Mm
Thrust:
290 N
Dimension:
Customized
Insulation Class:
F
Material:
Stainless Steel
Noise Level:
≤68dB(A)
Power:
3-phase 380V/50HZ
Protection Class:
IP68
Weight:
200-1500kg
Max Temperature:
60℃
Protection Level:
IP68
Power Supply:
220V/50Hz 380v50hz
Head:
1-50 M
Control System:
Variable Frequency Drive
Power Cord Length:
10m
Cable:
7 Core
Rated Frequency:
50Hz
Diameter Of Blade:
600 Mm
Motor:
100% Copper Wire
Color:
Sliver
Flow:
180-3000m3/h
Usage:
Mixing And Pumping
Flow Rate:
1-500 M3/h
Packaging Details:
wooden box
Supply Ability:
1000set/month
Highlight:

Reflux Submersible Mixer Pump

,

Submersible Mixer Pump QJB-W

,

380V 3 Phase Sewage Mixer

Product Description

QJB-W reflux mixer Industry submersible mixer for sewage treatment

QJB-W reflux mixer Industry submersible mixer for sewage treatment material on cast iron and SS 304 material





Submersible mixers Application:
The submersible mixers in our company include mixing agitator and low-speed flow propeller, mainly used for:
1. The purposes of mixing, agitating and making ring flows in the process of municipal and industrial sewage treatment: activated sludge tank, bioreactor tank, mixing tank, sludge silos, equalizing reservoir, sewage tank and etc.
2. The maintenance equipment for the landscape water environment, creating water flow.
3. Increasing the oxygen content in water and improving the quality of the water body.
4. Effectively preventing the sedimentation of the suspended substances.

CONDITIONS OF USAGE
The highest temperature of the media shall not exceed 40oC.
The pH value of the media: 5~9
The density of the media shall not exceed 1150Kg/m3
The depth of submersion shall not exceed 20m
The electric power supply: 380V, 50HZ
The motor: F class insulation and in accordance with IP68, continuous operating in 24hr
The submersible mixer must operate in the complete submersion into water











Submersible mixers performance parameter:



Submersible mixers construction:

Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer 0

Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer 1



Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer 2

Reflux Submersible Mixer Pump QJB-W 380V 3 Phase Sewage Mixer 3
